15L Capacity Pharmacy Appliance Steam Sterilizer from China manufacturer - Ningbo Joident Electronics Technology Co.,Ltd

15L Capacity Pharmacy Appliance Steam Sterilizer

Price:	1.0~5000.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: NOVO B+ 15

Production Capacity: 2000pcs/ month

Delivery Date: 15 working days

Electronic control: microprocessor

Test method: 3

Steel chamber: AISI 304

Water pump: 1 ULKA water pump

Conformity: 93/42/EEC, EN 13060, EN 610...

Means of Transport: Ocean,Air

Packing: Wooden / Carton

Brand Name: JOIDENT

Programs: 8

Cycle recording: Yes

Vacuum pump: Dual head

Alarm indications: 10

Certificate: CE

Max Work Pressure: 2.5 bar
Min Work Pressure:-0.9 bar
Max Temperature: 145℃
Water Volume for one cycle: 0.16L(min) 0.18L(max)

Clinic High Pressure Autoclave with Italy ULKA Water Pump

High Pressure Autoclave with Italy ULKA Water Pump/15L Capacity Pharmacy Appliance Steam Sterilizer

1- Main Features
(a) It is installed with BOWIE&DICK which measures the penetration of water steam.
(b) It has vacuum text which can make sure the ability of texting vacuuming.
(c) Safety lock and triple temperature.overload protecting.
(d) Warning message, Error is made easier to judge.

2-Products data

*Electronic Control microprocessor

*Programs 8

*Test method 3

*Cycle recording Yes

*Steel chamber AISI 304

*Temperature sensors in chamber1

*Vacuum pump Dual head

*Water pump 1 ULKA water pump

*Tank sensor 2,used water sensor & distilled water sensor

*Safety feature Electric-Mechanical dual interlock, Mechanical safety valve, alarms when door opened, Water level control, over heating control, over pressure protection, error messages viewed on the display

*Alarm indications 10

*Conformity 93/42/EEC, EN 13060, EN 61010

3- Packing details

Item Nr.	Power	Chamber size	Unit size	Packing size	Weight
Novo B+ 15	1500w	15L=Ø245X310mm	560X450X400mm	660X525X495mm	45kgs

4-Changing Door Gasket

Tool:A plain screw driver without sharp head is needed.

Disconnect the sterilizer from the power supply. Ensure that the sterilizer is cool and depressurized.

1) Hold verge of the seal by one hand softly, and another hand should be inserted the screwdriver into the gap between gasket and door, take out the seal slowly.

2) Once you take out one part of the seal, you can draw out the whole seal slowly. After taking out the seal, please check and clean the groove of gasket, so does the gasket, please replace the gasket if there is some damage.

3) Fix the clean gasket in initial door groove. Attention: the gasket should be imbedded in the groove equably. At first, please imbed the 4 spots equably into groove when fix the gasket, and then embed the other parts. After that, press the gasket equably by hand.

4) Attention: the inner edge of gasket may be ectropium during embedding it in the door groove, at this time; you'd better to tight it back to the groove by using the screwdriver carefully.
Clinic High Pressure Autoclave with Italy ULKA Water Pump

5- Payment details
T/T, L/C & west union acceptable.

6- Shipment

Express: 1 or 2pcs samples testing, express recommended.e.g: TNT,DHL,UPS etc. Shipping days 3-5days.
Air shipment: Between 3pcs and 5pcs, normal air shipment recommended. Shipping days 5-10days.
Sea shipment: More than 6pcs, normal sea shipment recommended. Shipping days around 30days.
